13_SERIES Double Outlet White

CURVED _ FLUSH _ MATTE

The ZETR double outlet is a recessed, trim-less, and completely flush outlet that integrates with the surrounding wall surface to provide minimal impact on the specified finish.

• No on/off switch required, all ZETR outlets contain an auto switching mechanism which is engaged when the plug pins are inserted into the outlet keeping the finished face completely flush with the surface.

• Suitable for new installations or retro-fit applications.

• Suitable for commercial and residential installations.

• Suitable for most surface thicknesses and varying wall types.

SPECIFICATIONS

• Surface Finish: Matte White

• Outlet Depth: 30 mm

• Outlet Body Height: 42 mm

• Outlet Width: 129 mm

• Embedding Depth: 32 mm (Including faceplate)

• Outlet Faceplate Height: 46 mm

• Outlet Faceplate Width: 132 mm

• Material: PC (polycarbonate) for skin

• Outlet Standard: Australian/New Zealand

• Product Certifications: RCM Registered Australia/ New Zealand

• Standards: AS/NZS 3112, AS/NZS 3100

• Rated Current: 10 A, 250 V, AC, 50 Hz

• Safety: Safety shutters included preventing insertion of foreign objects into the socket apertures.

• Patent: International Patent Pending

• Area: Interior

• IP: 20

SPECS AND DATA SHEET

MOUNTING

To be mounted within the surface to achieve flush finish in conjunction with one of the below ZETR mounting assemblies;

• Fixed Mounting Assembly (FMA) for plasterboard installation (53mm deep).

• Adjustable Mounting Assembly (AMA) for all other installations such as stone, tile, timber and rendered walls (56mm deep).

FACEPLATES

• The cover plate which is available in black and white is also designed to be match painted on site to the desired wall colour for true integration with the wall.

• We are currently working on ways to custom match ZETR faceplate to adjacent finishes, Please enquiry with us directly for information and availability lead times.
