ZETR INSTALLATION DOWNLOADS

Download ZETR Data Sheet - Specifications and Maintenance

Download Adjustable Mounting Assembly Installation Guide - Rendered Wall & Small Tile

Download Adjustable Mounting Assembly Installation Guide - Timber, Stone, Large Tile, Joinery

Download Fixed Mounting Assembly Installation Guide - Plasterboard Sheeted Walls

Download ZETR DXF Cutting Files for Adjustable Mounting Assembly for CNC, laser and water cutting. Please note this cutout needs to be a 135mm x 48mm oval shape cutout please remind the builders/joiners confirm and check this before cutting.

Download ZETR PDF Cutting Files for Adjustable Mounting Assembly

ZETR 13 SERIES INSTALLATION GUIDE

ZETR has developed two mounting assemblies that allow for flush installation of the outlet or switch grid. Along with an outlet or switch grid you will need to purchase one of the below mounting assemblies depending on the installation location.

ADJUSTABLE MOUNTING ASSEMBLY

ZETR's adjustable mounting assembly has a movable inner ring and allen key fastening system which allows the outer edge of the ring to finish flush in varying wall types, thicknesses and surfaces including plaster board, concrete, stone, tile, timber and rendered walls. This achieves a near invisible look for outlets and switches within the wall.

Screen Shot 2018-02-19 at 8.41.44 pm.png
Screen Shot 2018-02-20 at 12.12.31 pm.png



FIXED MOUNTING ASSEMBLY

The ZETR fixed mounting assembly has a set front depth for simple flush installation in plasterboard locations.
